Description
| General data of Cummins NTA855-G1A Diesel Engine for Generator Set | |
| Engine Model | Cummins NTA855-G1A |
| Type | 4 Stroke, In-line, 6 Cylinder |
| Displacement | 14 L |
| Bore&Stroke | 140*152 mm |
| Dry Weight(Fan to flywheel engine) | 1300 KG |
| Wet Weight(Fan to flywheel engine) | 1350 KG |
| Center of Gravity from Rear Face of Flywheel Housing | 704 mm |
| Center of Gravity Above Crankshaft Centerline | 140 mm |
| Performance Date of Cummins NTA855-G1A Diesel Engine for Generator Set | |
| Rated Output/Speed | 261KW/350HP/1500RPM |
| Standby Output/Speed | 291KW/390HP/1500RPM |
| Torque/Rated Output | 1662N.m/1500RPM |
| Torque/Standby Output | 1853N.m/1500RPM |
| Fuel Consumption/Rated Output | 61 L/h |
| Fuel Consumption/Standby output | 68 L/h |
| Technical data of Cummins NTA855-G1A Diesel Engine for Generator Set | |
| Aspiration | Turbocharged, Aftercooled |
| Fuel System | PT Pump Direct Injection |
| Coolant capacity-engine only | 20.8 L |
| Oil Pan Capacity-Low/High | 28.4/36 L |
| Idle speed | 575-650 RPM |
| Maximum No-Load Governed Speed | 1800 RPM |
| Maximum Overspeed Capability | 2700 RPM |
| Frictional loss power/rated output | 22 KW |
| Compression ratio | 14.5:1 |
| Piston Speed | 7.62 m/sec |
| Firing Order | 1-5-3-6-2-4 |
The above is general technical specification of Cummins NTA855-G1A diesel engine for generator set. It is also for us to supply the Cummins NTA855-G1A genuine engine parts and Cummins diesel generator set of this engine.
