Description
CCEC KTA38 series engine is a V-12 cylinder, 4-stroke, 4-valve, 38-liter displacement engine with a maximum torque of 5469 Nm. The power range is 750-1600 hp. KTA38 engine cylinder block cylinder head is an integrated design,which eliminates the occurrence of water leakage and oil leakage.
| General data of Cummins KTA38-G2 Diesel Engine for Generator Set | |
| Engine Model | Cummins KTA38-G2 |
| Type | 4 Stroke; 60° Vee; 12-Cylinder Diesel |
| Displacement | 38 L |
| Bore&Stroke | 159*159 mm |
| Dry Weight(fan to flywheel engine) | 3880 KG |
| Wet Weight(fan to flywheel engine) | 4111 KG |
| Center of Gravity from Rear Face of Flywheel Housing | 980 mm |
| Center of Gravity Above Crankshaft Centerline | 279 mm |
| Technical data of Cummins KTA38-G2 Diesel Engine for Generator Set | |
| Aspiration | Turbocharged Aftercooled |
| Fuel System | PT Pump Direct Injection |
| Coolant capacity-engine only | 118 L |
| Oil Pan Capacity-Low/High | 87/114 L |
| Idle speed | 725-775 RPM |
| Frictional loss power/rated output | 86 KW |
| Compression ratio | 14.5:1 |
| Piston Speed | 7.9 m/sec |
| Firing Order | |
| Performance Date of Cummins KTA38-G2 Diesel Engine for Generator Set | |
| Rated Output/Speed | 664KW/890HP/1500RPM |
| Standby Output/Speed | 731KW/980HP/1500RPM |
| Continuous Output/Speed | 604KW/810HP/1500RPM |
| Brake Mean Effective Pressure(rated output) | 1407 KPa |
| Brake Mean Effective Pressure(standby output) | 1551 KPa |
| Fuel Consumption/Rated Output | 167 L/h |
| Fuel Consumption/Standby output | 184 L/h |
The above is general technical specification of Cummins KTA38-G2 diesel engine for generator set. It is also for us to supply the Cummins KTA38-G2 genuine engine parts and Cummins diesel generator set of this engine.
Remarks:
(1) If you need the other engine except KTA38-G2 , then the Cummins 4B, 6B, 6C, 6L, QSB, QSC, QSL, ISL, ISB, ISD, QSM11, ISM11, M11, NTA855, KTA19, KTA38 and KTA50 engine be your choice, please further contact our sales.
(2) We can provide the diesel generator set for both open type and silent with enclosure, together with the generator and control panel. If you required the Cummins KTA38-G2 engine parts, we also can be your help.
(3) The above diesel engine KTA38-G2 is from Cummins CCEC factory, which is used for the generator set, we also can supply this engine for the marine application.
(4) If the engine details you need are not in our above list, please further contact us to check for you. Maybe some information are not updated.
