Cummins 6CTA8.3-G2 Diesel Engine for Generator Set
| General data of Cummins 6CTA8.3-G2 Diesel Engine for Generator Set | |
| Engine Model | Cummins 6CTA8.3-G2 |
| Type | 6 cylinder in line |
| Displacement | 8.3 L |
| Bore&Stroke | 114×135 mm |
| Dry Weight | 637 KG |
| Dimension(L*W*H) | 867*544*998mm |
| Center of gravity from front face of block | 427 mm |
| Center of gravity above crankshaft centerline | 163 mm |
| Technical data of Cummins 6CTA8.3-G2 Diesel Engine for Generator Set | |
| Aspiration | Turbocharged & Aftercooled |
| Fuel System | FR91961: BYC PB/GAC FR92995: BYC PB/SEGMA FR91651: BYC PB/FORTRUST |
| Governor Regulation | ≤3% |
| Coolant capacity-engine only | 12.3 litre |
| Mimimum Lubricant Capacity(pan+filter) | 27.6 L |
| Idle speed | 700-900 RPM |
| Frictional loss power/1500rpm | 17 KW |
| Frictional loss power/1800rpm | 22 KW |
| Compression ratio | 17.3:1 |
| Piston Speed/1500rpm | 6.8 m/sec |
| Piston Speed/1800rpm | 8.1 m/s |
| Performance Date of Cummins 6CTA8.3-G2 Diesel Engine for Generator Set | |
| Rated Output/Speed(1500rpm) | 163KW/218HP |
| Standby Output/Speed(1500rpm) | 180KW/241HP |
| Continuous Output/Speed(1500rpm) | 133KW/178HP |
| Rated Output/Speed(1800rpm) | 170KW/228HP |
| Standby Output/Speed(1800rpm) | 187KW/251HP |
| Continuous Output/Speed(1800rpm) | TBD |
| Fuel Consumption/rated output(1500rpm) | 212 g/KW.h |
| Fuel Consumption/standby output(1500rpm) | 218 g/KW.h |
| Fuel Consumption/rated output(1800rpm) | 213 g/KW.h |
| Fuel Consumption/standby output(1800rpm) | 216 g/KW.h |
Standard Conditions: Data shown above are based on :
- Engine operating with fuel system, water pump, lubricating oil pump, air cleaner & exhaust silencer, not included are battery charging alternator, fan and optional driven component
- Engine operating with diesel fuel corresponding to grade No.2DperASTM D975
- ISO-3046, Part 1, Standard Reference Conditions of:29.53 in.Hg. [100 kPa] barometric pressure (361ft.[110m] altitude), 25 degree Celsius air temperature and a relative humidity of 30%
The above is general technical information of Cummins 6CTA8.3-G2 diesel engine for generator set. It is also for us to supply the Cummins 6CTA8.3-G2 genuine engine parts and Cummins diesel generator set of this engine.
